输入电压
Nominal: 5V, 12V, 15V, 24V; Range: 4.75-5.25V, 11.4-12.6V, 14.25-15.75V, 22.8-25.2V
输出电压
5V, 15V
输出电流
Max: 400mA (for 5V), 133mA (for 15V); Min: 40mA (for 5V), 13mA (for 15V)
效率
70% to 76%
开关频率
55KHz to 100KHz kHz
隔离电压
Min: 1000 VDC
隔离电阻
Min: 1000 MΩ
线性调整率
±0.25% (For Vin change of ±5%)
负载调整率
±1.5% (10% to 100% full load)
输出电压精度
±3% (100% full load)
温度漂移
0.03%/°C (100% full load)
纹波和噪声
Ripple: Typ 20, Max 30 mVp-p; Noise: Typ 50, Max 100 mVp-p (20MHz Bandwidth)
工作温度
-40°C to 85°C
存储温度
-55°C to 125°C
引脚温度
Typ: 20°C, Max: 30°C (1.5mm from case for 10 seconds)
外壳温升
Max: 300°C
短路保护
Continuous
平均无故障时间
3500 K hours hrs
重量
2.8 g
封装
SIP10 Package
认证
RoHS compliant, CE, REACH
